NOTE!! This is the FSX version of my MSFS Touch Portal Plugin.

• It can also connect to MSFS (2020) but will lack some features like WASM and HubHop integration, and setting multiple SimConnect Event values.
• Both plugins can be installed in Touch Portal at the same time and operate independently (they have unique TP Actions, States, and Events).
• Pages/buttons made for the MSFS version of the plugin will NOT work with this version, and vice versa.
  • I added FSX versions of a "Connect" button and Starter/Example page to the wiki.
• It has been tested with the original boxed Deluxe version with SP2 and Accelleration Pack installed.
• It should work with any later version, including Steam and Accelleration Edition.
• It may work with some versions of Prepar3D.
• You should not need to have any specific version of the SimConnect client installed (all libraries are included in the plugin.

Overview

This plugin provides tools to build two-way interactive interfaces between Touch Portal macro launcher software and Flight Simulators which use older 32-bit SimConnect, such as Microsoft Flight Simulator X (FSX). The plugin makes available new Touch Portal Actions, Connectors, States, and Events for creating buttons and pages suitable for virtually any simulated aircraft, component, or system.

Features

• Connects to local or remote simulators with SimConnect.
• Allows getting data variables from simulator at regular intervals, such as flight instrument readings, control surface positions, or switch states.
• Allows triggering any interactive aircraft event via Touch Portal Actions, such as setting switches, adjusting control surfaces, radio frequencies, and so on.
• Use Touch Portal "Sliders" to control a value within any range, and/or provide visual feedback to simulator variable changes (eg. a throttle slider can both control the sim throttle and show the actual position when the throttle is moved with mouse/joystick/keyboard).
• Completely configurable to request any variable or trigger any event supported by the connected simulator.
• Supports simulator system events (such as "flight loaded" or "sim started") as Touch Portal Events.
• Allows simultaneous usage from multiple networked Touch Portal devices.
• Includes database of all SimConnect Events and SimVars imported from MSFS online documentation.

Downloads and Repository

The project is published and maintained at: https://github.com/mpaperno/MSFSTouchPortalPlugin

MSFS TOUCH PORTAL PLUGIN README
LATEST RELEASE DETAILS AND DOWNLOADS
MSFS TOUCH PORTAL PLUGIN DOCUMENTATION WIKI
TOUCH PORTAL GUIDES

Please follow the links above for more information, documentatoin, example pages, and the latest releases.

IF YOU DOWNLOAD FROM HERE: Unzip the file you downloaded here and extract the ".tpp" file inside. Then it can be imported into Touch Portal. Please see the README for further instructions.

Support and Discussion

Please use the GitHub Issues pages for bug reports and concise feature requests. Use the Discussions forum for general conversation on any related topic like suggestions or support questions.

There is also a Discord support forum on my server, and discussion rooms on my Discord server channel #msfs-general and at Touch Portal's Discord server channel #msfs2020.

Copyright (c) 2020 Tim Lewis;
Copyright Maxim Paperno, all rights reserved;
Copyright MSFSTouchPortalPlugin Project Contributors
License: GPLv3.
See repository for license details, copyright, and disclaimer information.

Najnowsze zmiany for 1.5.0.0

Release v1.5.0.0 (1050000)

These notes only list changes relevant to the FSX version of the plugin. For the complete list of changes please check the official release page: https://github.com/mpaperno/MSFSTouchPortalPlugin/releases/tag/1.5.0.0

## Changes since v1.4.3.3:

* Fixed "Plug-in performance issue detected" Touch Portal v4 warning message. ([#63](https://github.com/mpaperno/MSFSTouchPortalPlugin/issues/63))
* Added ability in the "Clear Variable Definitions" action to remove variable requests by the file they were loaded from and by the type of variable.
* For Touch Portal v4:
* The plugin will now show up in the "Games" category instead of "Misc."
* Descriptions of each setting are now available in TP's "Plug-in Settings" dialog by hovering over the question mark icons.
* Updated to use .NET 6 runtime environment and dependencies (up from .NET 5). All required components are included in the distribution as before.

### Related
* The user-interface part of my WASimCommander project, [WASimUI](https://github.com/mpaperno/WASimCommander/tree/next#desktop-gui), now supports importing and exporting custom variable requests in the plugin's format.
That includes a new interface for editing plugin-specific information like category, state ID, name, default value, and formatting.
It can be downloaded at that project's [Releases](https://github.com/mpaperno/WASimCommander/releases/tag/1.2.0.0) page.
